ISO Category II

ISO CATEGORY II

Analysis I

Have you been a part of a Vibration Analysis program at your facility for some time now? Do you know you could do more to contribute to the success of the program? Do you need to expand your knowledge base? Our ISO Category II Seminar is the perfect way to accomplish these tasks and more!

  • OVERVIEW

    • 3-Day Class: Tuesday - Thursday, 8am - 6pm
    • Certification Testing: Friday 8am - 11am

    This three-day seminar builds from the ISO CATEGORY I course and provides the essential information in a generic manner for implementing a successful PdM program and is intended as an introduction to vibration analysis and predictive maintenance.



    Emphasis is on how to detect a series of fundamental machinery problems from our world-renowned Illustrated Vibration Diagnostics Chart that describes: (1) unbalance, (2) misalignment, (3) rotor eccentricity, (4) mechanical looseness, (5) belt drive problems, and (6) soft foot problems using both spectral and phase analysis.



    Introductory information for detection of resonance, rolling element bearing, gear, flow related and electrical problems is also given.



    A proven tabulated procedure, How to Specify Meaningful Overall and Spectral Band Alarms for a Variety of Machinery Types and Operating Speeds clearly shows how to specify alarm levels for individual frequency bands; the beginning and ending frequencies for each of the available spectral alarm bands; recommended frequency range, #FFT lines, number of averages and proper vibration parameter for each point taking into account the machine type, operating speed range, machine components and drive type.



    Measurement pitfalls are discussed, along with their effect on problem diagnoses and evaluation of problem severity.



    Real-world case histories are provided to clearly illustrate the diagnostic methods taught and how they were used to detect and resolve the problems plaguing the machines or how the root causes of the problems were uncovered. (100 page Case History Section)

  • INTENDED AUDIENCE

    • Analysts having less than one year of experience

  • PREREQUISITES

    • Recommended Full-Time PdM Vibration Experience = 3 to 6 Months
    • However, if Vibration Specialist Certification is desired, a person with at least 6 months vibration spectrum analysis experience is usually more successful.
    • General familiarity with using a calculator and a computer is highly recommended.
    • Good math skills and simple Algebra, primarily solving for one variable, is helpful.
    • Previous attendance of the ISO CATEGORY I Seminar is strongly recommended, or equivalent vibration analysis experience.
    • Take the Vibration Assessment Quiz to help you decide if you should attend ISO CATEGORY I or ISO CATEGORY II Seminar.

  • SEMINAR FEES & OPTIONAL EXAM

    SEMINAR FEE: $1795


    OPTIONAL CERTIFICATION EXAM: $300


    CLICK HERE TO REGISTER NOW


    A 5% DISCOUNT will be given for full payments received at least 60 DAYS  prior to the seminar start date.


    Seminars Fees include textbook, breaks, and lunches.

ISO Category II

Seminar Agenda

Introduction to Vibration Analysis and Predictive Maintenance
  • Seminar Overview
  • What is Vibration and How Can it be Used to Evaluate Machinery Condition?
    • What is Frequency and How Does it Relate to a Time Waveform?
    • What is Vibration Displacement, Velocity, and Acceleration?
    • How to Convert From One Vibration Parameter to Another (in/sec to g, etc.)
    • What is Phase?
    • What is a Vibration Spectrum (Also Called an “FFT" or “Signature")
    • Effect on Frequency Accuracy of Number of FFT Lines
    • Difference Between RMS, Peak, and Peak-To-Peak Amplitude and its Significance
    • When to Use Displacement, Velocity, or Acceleration
    • How Much is Too Much Vibration?
  • Overview of the Strengths and Weaknesses of Typical Vibration Instruments
  • Overview of Various Vibration Transducers and Their Optimum Applications
  • Role of High Frequency Enveloping (HFE) and HFD in Detecting & Tracking Certain Faults
    • HFE includes the following (in alphabetical order):
      • Acceleration Enveloping
      • Amplitude Demodulation
      • PeakVue
      • Shock Pulse
      • Spike Energy
  • Introduction to Vibration Signature Analysis and How it is Used to Evaluate Machine Operating Condition
    • Overview of 5-Page Illustrated Vibration Diagnostic Chart
      • Mass Unbalance
      • Eccentric Rotors
      • Bent Shaft
      • Misalignment
      • Mechanical Looseness, Improper Component Fit, and Soft Foot
      • Tracking of Rolling Element Bearing Health Using Vibration Signature Analysis
      • Belt Drive Problems
      • Electrical Problems in Motors
  • Proven Method for Specifying Spectral Band Alarm Levels and Frequencies Using Today's Predictive Maintenance Software Systems
  • Guidelines for Vibration Acceptance Testing for New and Rebuilt Machines
  • Operating Basics of Common Machines and Recommended Locations to Acquire Vibration Measurements
  • Actual Case Histories of Vibration Diagnostics on Various Machine Types

Seminar Fee: $1795

A 5% DISCOUNT will be given for full payments received at least 60 DAYS  prior to the seminar start date.

Seminars Fees include textbook, breaks, and lunches.

When registering for a seminar, please do not forget to fill out the SEMINAR REGISTRATION FORM either before or after visiting our ONLINE STORE to make sure we have all the correct information needed to properly fill out all Certificates, as well as the information we need to best tailor the seminar to meet your individual needs based on the instrumentation used at your company.
