Practical Field Balancing

PRACTICAL FIELD BALANCING

Are you unsure whether your machine is dealing with unbalance or some other issue? Do you know how to confirm if unbalance is the main problem? Do you "chase your tail" when you try to balance a machine? Do you know when to stop your balance procedures?

Our Field Balancing Seminar may be just what your site personnel need.

  • OVERVIEW

    • 3-Day Class: Tuesday - Thursday, 8am - 5pm
    • Optional Certification Testing is available Thursday afternoon

    This 3-day seminar provides HANDS-ON practice with your company’s exact field balancing equipment.  It is recommended the students bring their own field balancing analyzer to class to gain practical knowledge and experience they can bring back with them.


    This class also helps students learn how to determine if balance is the primary source of vibration and what type of unbalance condition exists on the machine.  Students will learn various balance techniques including single-plane and dual-plane balancing and will be introduced to no-phase and one-run balance techniques.


    Students will also learn industry standards for balancing tolerances and how to determine what is the proper amount of unbalance to give your company better field balances to help you get the most life out of your equipment.

  • PRIMARY OBJECTIVES

    • Instruct how to confirm that unbalance is one of the dominant problems (using straightforward spectral & phase analysis).
    • Use Hands-on Demonstrations to teach how to properly balance a variety of machinery using both graphical methods and data collectors with balancing programs.
    • Teach single-plane and two-plane field balancing techniques using a variety of today’s data collectors.
    • Teach special balancing techniques required on overhung rotors.
    • Provide and clearly explain today’s balancing tolerances.

  • PREREQUISITES

    • Previous vibration analysis experience is recommended but is not required prior to attending this seminar.
    • Previous field balancing experience is helpful but is not required prior to attending this seminar.
    • General familiarity with using today’s data collectors or portable balancing instruments is also beneficial (a variety of such instruments will be demonstrated during interactive class exercises).
    • Good math skills and the ability to use and interpret graphs and tabular information will be beneficial in order to maximize understanding.

  • SEMINAR FEES & OPTIONAL EXAM

    SEMINAR FEE: $1295


    OPTIONAL CERTIFICATION EXAM: $225


    CLICK HERE TO REGISTER NOW


    A  5% DISCOUNT will be given for full payments received at least 60 DAYS  prior to the seminar start date.


    Seminars Fees include textbook, breaks, and lunches.

Practical Field Balancing

Seminar Agenda


  • Definition of Unbalance





  • Types of Unbalance:
  • Static Unbalance
  • Couple Unbalance
  • Quasi-Static Unbalance
  • Dynamic Unbalance





  • Rigid Versus Flexible Rotors



  • Causes of Unbalance:
    • Assembly Errors
    • Casting Blow Holes
    • Fabrication Tolerance Problems
    • Key Length Problems
    • Rotational Distortion
    • Deposit Buildup or Erosion
    • Unsymmetrical Design
  • How to Ensure the Dominant Problem is Unbalance:
    • Review of Typical Spectra and Phase Behaviors For Common Machinery Problems
      • Mass Unbalance
      • Eccentric Rotor
      • Bent Shaft
      • Misalignment
      • Resonance
      • Mechanical Looseness/Weakness
    • Summary of Phase Relationships For Various Machinery Problems
    • Summary of Normal Unbalance Symptoms



  • Field Balancing Techniques
  • Recommended Trial Weight Size and Placement
  • Single-Plane Balancing Using a Portable Data Collector
  • Two-Plane Balancing Using a Portable Data Collector
  • Balancing Overhung Rotors
  • By Classic Single-Plane Static-Couple Method
  • By Classic Two-Plane Static-Couple Method
  • Splitting Balance Correction Weights
  • Combining Balance Correction Weights
  • Effect of Angular Measurement Errors On Potential Unbalance Reduction
  • Commonly Encountered Balancing Problems



  • Recommended Vibration and Balance Tolerances:
    • Vibration Tolerances
      • Overall Vibration Specifications
      • Spectral Alarm Band Specifications
    • Balance Tolerances on Allowable Residual Unbalance
      • ISO 1940 Balance Quality Grades
      • How to Determine Residual Unbalance Remaining in a Rotor After Balancing
      • API Balance Tolerances
  • Hands-On Instruction:
    • Hands-On Demonstration of Single-Plane Balancing
      • Using a Portable Data Collector
    • Hands-On Demonstration of Two-Plane Balancing
      • Using a Portable Data Collector
    • Hands-On Demonstration of Balancing Overhung Rotors
      • Using Classic Single-Plane Static-Couple Method
      • Using Classic Two-Plane Static-Couple Method
    • Demonstration of Splitting Balance Correction Weights
    • Demonstration of Combining Balance Correction Weights
  • Balancing Machines - Soft Versus Hard Bearing

Seminar Fee: $1295

A  5% DISCOUNT will be given for full payments received at least 60 DAYS  prior to the seminar start date.

Seminars Fees include textbook, breaks, and lunches.

When registering for a seminar, please do not forget to fill out the SEMINAR REGISTRATION FORM either before or after visiting our ONLINE STORE to make sure we have all the correct information needed to properly fill out all Certificates, as well as the information we need to best tailor the seminar to meet your individual needs based on the instrumentation used at your company.
